DS-KIS607-S IP Video Interkom Kit
DS-KIS607-S IP Video Interkom Kit
IP Video Intercom Kit
- Convenient Hik-Connect APP Mobile Control
- One call button for easier calls
- Standard PoE power supply
- Stores messages and captured pictures in the TF card
- Including: Door station x1, Indoor station x1, PoE Switch x1, 32GB TF card x1
- Door station/System parameters
- Operation systemEmbedded Linux operation system
- Flash32 MB
- RAM256MB
- Door station/Video parameters
- Supplement lightIR light, up to 3 m
- Resolution
Main stream: 1920 × 1080p, 720p
Sub stream: 640 × 480p
- Lens2MP HD camera
- Wide dynamic range (WDR)Support 120 dB
- FOVHorizontal: 131° Vertical: 78°
- Video Compression StandardH.264
- Motion detectionSupport
- Door station/Audio parameters
- Audio input1 built-in omnidirectional microphone
- Audio output1 Built-in loudspeaker
- Audio qualityNoise suppression and echo cancellation
- Volume adjustmentAdjustable
- Audio compression standardG.711 U
- Audio compression Rate64 Kbps
- Door station/Network parameters
- Network protocolTCP/IP, RSTP
- Door station/Device interfaces
- Network interface1 RJ-45, 10/100 Mbps self-adaptive
- RS-4851
- Alarm input4
- Lock control1 relay, Max. 30 VDC 2 A
- Exit button1
- TAMPER switch1
- Door contact input1
- Door station/General
- Button1 physical button(s)
- Power consumption＜ 10 W
- Working temperature-40 °C to 55 °C(-40 °F to 131 °F)
- Working humidity10% to 95% (no-condensing)
- Dimension138 mm × 65 mm × 27 mm (5.4" × 2.6" × 1.1")
- InstallationSurface mounting
- Protection levelIP65
- Indicator2
- Application environmentOutdoor
- Power supply
IEEE802.3af, standard PoE
12 VDC
- Net weight: 0.190 kg Gross weight: 0.414 kg
- Indoor station/System parameters
- Operation systemEmbedded Linux operation system
- Memory128 MB
- Flash32 MB
- Indoor station/Display parameters
- Display screen7-inch colorful TFT screen
- Display resolution1024 × 600
- Operation methodCapacitive touch screen
- Indoor station/Audio parameters
- Audio input1 built-in omnidirectional microphone
- Audio output1 built-in loudspeaker
- Audio qualityNoise suppression and echo cancellation
- Audio compression standardG.711 U, G.711 A
- Audio compression Rate64 Kbps
- Volume adjustmentAdjustable
- Indoor station/Capacity parameters
- Notice capacity200
- Linked indoor extensions capacity16
- Indoor station/Network parameters
- ProtocolTCP/IP, SIP, RTSP
- Wi-Fi2.4 GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n
- Indoor station/Device interfaces
- Network interface1 RJ-45 10/100 Mbps self-adaptive
- RS-4851
- Alarm input8-ch alarm inputs
- Alarm output2
- TF cardMax to 128 G
- Indoor station/General
- Power consumption≤ 5 W
- Power supply12 VDC,IEEE802.3af, Standard PoE
- Working temperature-10 °C to 50 °C (14 °F to 122 °F)
- Working humidity10% to 90%
- Dimension (L x W x H)175 mm × 113.5 mm × 21 mm (6.9" × 4.5" × 0.83")
- InstallationWall mounting, table mounting
- Application environmentIndoor
- Net weight: 355 g (0.8 lb) Gross weight: 683 g (1.5 lb)
